IGCC10003 LED Inground Light
0~1m Height Application
■ Minimalistic appearance design.
■ High-strength die-cast aluminum housing.
■ Highly reliable and impact-resistant toughened
glass.
■ Humanized anti-glare optical design.
■ Multiple options of visually comfortable and
precise optical lens.
■ High-performance electronic design and reliable
heat dissipation.
■ Intelligent stepless dimming technology adopted.
| Wattage | 3W | 3W | 3W |
|---|---|---|---|
| Color Temperature | White | RGB | RGBW |
| Luminous Flux | 210lm@4000k | ||
| Beam Angle (50%Imax) | 6°/8° / 15° / 30° / 40° / 60° / 80° / 30*60° | ||
| LED Brand | CREE / NICHIA / OSRAM / LUMILEDS / EPISTAR | ||
| Input Voltage | DC24V/AC220V | DC24V | DC24V |
| Protection Class IEC | III/I | ||
| Control | DMX / ON-OFF | DMX | DMX |
| Finish | Powder coating | ||
| Housing | Die-cast aluminum ADC12 | ||
| Cover | Toughened glass | ||
| IP Rating | IP67 | ||
| IK Rating | IK06 | ||
| Mounting | Recessed | ||
| Operation Temperature | -35°C ~ 60°C (-31°F ~ 140°F) | ||
| Storage Temperature | -40°C ~ 70°C (-40°F ~ 158°F) | ||
| Lifespan | >50,000Hrs (Ta=35°C@L70) | ||
| Certificate | CE / RoHS | ||
■ Please contact our sales team for more product details.
■ Archillumi work on global lighting market. Products can be customized based on special requirement.
