WWL2924 LED Wall Washer Light
0.5~2m Height Application
■ Minimalistic appearance design
■ Cost-effective product
■ High-strength aviation aluminum housing.
■ Highly reliable and impact-resistant toughened glass.
■ Optical dark-free zone design for seamless splicing of light.
■ Multiple options of visually comfortable and precise optical lens.
■ International standard DMX512 protocol.
| Wattage | 24W | 12W | 15W |
|---|---|---|---|
| Color Temperature | White | RGB | RGBW |
| Luminous Flux | 1920 lm @4000K | ||
| Beam Angle (50%Imax) | 17° / 23° / 33° / 46° / 20*40° / 25*80° | ||
| LED Brand | CREE / NICHIA / OSRAM / LUMILEDS | ||
| Input Voltage | DC24V | ||
| Protection Class IEC | III | ||
| Control | DMX / ON-OFF | DMX | DMX |
| Finish | Powder coating | ||
| Housing | Extruded aluminum 6063 | ||
| Cover | Toughened glass | ||
| IP Rating | IP66 | ||
| IK Rating | IK06 | ||
| Mounting | Adjustable bracket | ||
| Operation Temperature | -35°C ~ 60°C (-31°F ~ 140°F) | ||
| Storage Temperature | -40°C ~ 70°C (-40°F ~ 158°F) | ||
| Lifespan | >50,000Hrs (Ta=35°C@L70) | ||
| Certificate | CE / RoHS | ||
■ Please contact our sales team for more product details.
■ Archillumi work on global lighting market. Products can be customized based on special requirement.
