PL3630 LED Pixel Light
Minimalistic and High brightness
Media Facade Application
■ Small and skillful design
■ The outdoor self-cleaning design ensures greater performance and higher reliability.
■ Weathering and fireproof PC housing
■ Intelligent stepless dimming technology adopted.
■ High brightness contrast
■ International standard DMX512 protocol.
| Wattage | 1.5W | 1.5W | 1.8W |
|---|---|---|---|
| Color Temperature | White | RGB | RGBW |
| Luminous Flux | 113lm @4000K | ||
| Beam Angle (50%Imax) | 110° | ||
| LED Brand | CREE / NICHIA / OSRAM / LUMILEDS / EPISTAR | ||
| Input Voltage | DC24V/DC48V | ||
| Protection Class IEC | III | ||
| Control | DMX / ON-OFF | DMX | DMX |
| Finish | Rough black | ||
| Housing | High strength engineering PC | ||
| Cover | High strength optical PC | ||
| IP Rating | IP65 | ||
| IK Rating | IK10 | ||
| Mounting | Buckcle | ||
| Operation Temperature | -35°C ~ 60°C (-31°F ~ 140°F) | ||
| Storage Temperature | -40°C ~ 70°C (-40°F ~ 158°F) | ||
| Lifespan | >50,000Hrs (Ta=35°C@L70) | ||
| Certificate | CE / RoHS / EMC | ||
■ Please contact our sales team for more product details.
■ Archillumi work on global lighting market. Products can be customized based on special requirement.
